ADVANTAGE CARGO TRAILER
(V-FRONT)
STANDARD FEATURES
- 205/75R15 Range Tires *
- White Spoke Wheels – Bolt Pattern 5 – 4 1/2 *
- A-Frame Tongue w/ Safety Chains and Hooks *
- Genuine Dexter Torflex® Axle(s) w/E-Z Lube® Hubs *
- 3/8″ Plywood Walls – 16” OC
- .030 Exterior Aluminum (Colors Available)
- .032 Seamless 1 pc. Aluminum Roof – LIFETIME WARRANTY
* 8′ x 22′ & 24′ trailers require (2) 6000# Dexter Spring Axles (9990 GVWR), 225/75R15 D Range Tires, 6-bolt wheels, 16″ OC Floor Crossmembers and Triple A-Frame tongue
- 3/4″ Plywood Floor – Painted Both Sides – LIFETIME WARRANTY
- 4″ Formed C-Channel Crossmembers – 24″ OC *
- Structural Steel Tube Frame
- Aluminum Diamond Plate Corners
- Smooth Aluminum Fenders
- Hot Dipped Galvanized Door Hardware
- LED Lighting – LIFETIME WARRANTY
TRAILER DIMENSIONS
SPECIFICATIONS
| Single Axle Advantage Cargo Trailer | Tandem Axle Advantage Cargo Trailer | ||||||
|---|---|---|---|---|---|---|---|
| 5' WIDE | 6' WIDE | 7' WIDE | Size | 5'W HD | 6'W HD | 7'W HD | 8'W HD * |
| 8.5'/10'/12' | 10'/12' | 10'/12' | Available Lengths | 10'/12'/14' | 10'/12'/14'/16' | 10'/12'/14'/16'/18'/20' | 12'/14'/16'/18'/20'/22'/24' |
| 2' 4" | 2' 10" | 3' 4" | Interior Nose Length to Point | 2' 4" | 2' 10" | 3' 4" | 3' 10" |
| 2990# | 3500# | GVWR * | 7000# | ||||
| 3500# Dexter Torflex Axle | Axle(s) * | 2 - 3500# Dexter Torflex Axles | |||||
| Optional | Standard | Electric Brakes | Standard | ||||
| 2" | Coupler/Hitch Ball Size | 2 5/16" | |||||
| Flat 4 Pole | 7 Pole | Light Plug Connector | 7 Pole | ||||
| 2" x 4" | Frame | 2" x 4" | 2" x 4"/5" | 2" x 4"/5"/6" | 2" x 6" | ||
| 82" | 92" | Overall Exterior Height | 82" | 92"/93" | 92"/93"/94" | 103" | |
| 82" | 94" | 99 1/2" | Overall Exterior Width | 82" | 94" | 99 1/2" | 98" |
| 56" | 68" | 80" | Interior Box Width | 56" | 68" | 80" | 92" |
| 62" | 72" | Interior Height | 62" | 72" | 78 1/2" | ||
| 54"W x 58"H | 66"W x 68"H | 78"W x 68"H | Double Rear Doors (standard) | 54"W x 58"H | 66"W x 68"H | 78"W x 65" - 68"H | 90"W x 73"H |
| 54"W x 55"H | 66"W x 65"H | 78"W x 65"H | Ramp Rear Door (optional) | 54"W x 55"H | 66"W x 65"H | 78"W x 65"H | 90"W x 72"H |
| Optional | Standard | Side Man Door | Standard | ||||
| Aluminum - 24" OC | Alumimum - 16"OC | Roof Bows | Aluminum - 24" OC | Alumimum - 16"OC | Steel Hat Channel - 24" OC | ||
| 2000# | Tongue Jack | 2000# | 2000#/5000# | 5000# | |||
| 16" | Aluminum Front Stone Guard | 16" | 24" | ||||
| * 8′ x 22′ & 24′ trailers require (2) 6000# Dexter Spring Axles (9990 GVWR), 225/75R15 D Range Tires, 6-bolt wheels, 16″ OC Floor Crossmembers and Triple A-Frame tongue | |||||||
TRAILER OPTIONS
COLOR OPTIONS
GET A QUOTE
Need a quote for a Cargo Trailer? Please click the button below and fill out the necessary information. Please be sure to know the trailer size(s), closest dealer and color option before filling out the form.
